• Three Dimensional Unfolding – Quickly define and unfold 3D wireframe parts.
• Two Dimensional Unfolding – Unfold section views in standard 2D orthographic drawings to assist in flat part development.
• Two Dimensional Progressive Unfolding – Perform partial unfolding of 2D section views to aid in the development of progressive die and roll form tooling.
• User Configurable Calculations – Material based bend calculation charts can be populated with known manufacturing data for increased accuracy.
• Geometry Validation – Geometry is analyzed and “cleaned up” within tolerance to produce valid sheet metal parts.
• Bend Chart Creation – A bend chart is automatically created providing details for each part bend including bend allowance, neutral axis, bend radius, bend angle, bend direction, and required over-bend angle.
• Corner Joint Development – Create a complex corner joint on any inclusive angle from a standard 2D orthographic drawing.

Click here for expanded SS-Unfold feature list -> SS-Unfold Expanded Feature List.pdf
